The Connectors are Custom Fit to the Outer Diameter of the Armor. Optional Materials by Request: Stainless Steel, Nickel-Plated Brass

Tray cables encompass TC-ER rated products, typically 600V or 1000V power cables in single- or multi-conductor formats, often with FT4 or FT4-ST1 flame ratings for low-smoke options.

RW90 LSZH cables are available in 600V or 1000V ratings, in single- or multi-conductor configurations with various sizes. They feature cross-linked polyethylene (XLPE) insulation rated for 90°C wet or dry operation, combined with low smoke zero halogen jacketing and FT4-ST1 plus TC-ER ratings.

ACIC (Armored Control and Instrumentation Cable) is rated at 300V and commonly features shielded pairs or triads (e.g., 18 AWG tinned copper conductors). It is designed for reliable signal transmission in electrically noisy environments.

Teck LSZH cables are armored power cables rated at 1000V, available in multi-conductor configurations. They feature low smoke zero halogen jackets and meet stringent FT4-ST1 flame and smoke requirements.

Traction power cables are specialized single-conductor cables rated at 2000V, designed for railway and transit applications. These cables comply with CSA FT4-ST1 and TC-ER ratings, allowing exposed runs and installation in cable trays per Canadian Electrical Code requirements.

Temporary lighting for tunnels and many other applications. A lighting system that supports visual perception and consistent light levels. Ease of installation and overall cost savings.

The RTX is a heavy duty, harsh environment luminaire designed for rail and tunnel applications. Its 1? low-profile design enables RTX to be mounted to the tunnel wall using quick latch hangars or via snake rack and keeps the fixture out of the dynamic envelope. Push-and-click connectors make installation easy to terminate to any wiring box used in today’s tunnel environment. The innovative driverless technology is EMI-silent and connects directly to AC line voltage, providing extreme reliability and zero maintenance.

NFPA 130 compliant patch cords, using HUB-Link® communications cables, are a plug and play solution that ensures reliable connections between critical equipment in transit systems to help keep passengers safe. Supporting contractors, installers and engineers, these patch cords are pre-assembled and pre-tested to save time and labor during installation. (Patch)

HUB-Link® Transit Communications NYCT Approved cables are ideal for the following applications: • Outside Plant Transit, Subways and Tunnels • Various Mass Transportation Facilities • Voice and Data Telephone Circuits • Installed in Pathways and Termination Closets (HT01)
